A 12 V PIR motion detector infrared PIR switch is used to sense the movement of people, animals, or other objects. This electric sensor switch can be utilized in mechanically-activated lighting systems. 12 volts dc movement detector light switch is with load capacity, strong anti-jamming capability. PIR on-off switch can automatically identify day and night, and the external environment illuminance can freely choose the starting job.
Features Of Outdoor 12V DC Automatic Infrared PIR Motion Sensor Switch For LED Light
- Load capacity, strong anti-jamming capability
- Built-human infrared sensor module, sensor module light effects, delay switch module.
- People into the sensing range can be automatically opened, after leaving the automatic delay off, can automatically identify day and night, and the external environment illuminance can freely choose the starting job
- Automatic work to do in the evening, during the day and closed. Users can adjust; light time is adjustable and can be adjusted by the user according to local conditions
- Color: Black
- Detection range: 180 degree
- Operating voltage: DC 12 V
- Detection distance: 15 m (24 Degrees Celsius)
- Delay Time:15 seconds to 7 minutes
- Installation height: 1.8m-2.5m
- Material: ABS
- Installation: Open type, (hole 16mm) installation, adjusting for the next button
PIR Motion Sensor Adjustment:
- LUX: Adjust the working time (Day or Night)
- Sun position (Maximal): the sensor will work for the entire daytime
- Moon position (Minimum): the sensor will work only at night mechanically
- TIME: Adjust the delay time of the sensor (6sec~6min)
- SENS: Adjust the sensitivity of the sensor
- Caution: The Brown wire is Firewire; the blue wire is Neutral wire; the green-yellow wire is Ground wire.
1 x12V Outdoor Security PIR Human Body Motion
